Mikro NX301A / NX302A-240A Earth Leakage Relay For 50Hz System 198-265V AC

Category:

Earth Leakage Relay, Mikro

Self-powered multi-function digital panel meter
Replaces multiple single-measurement meters with one meter
Phase loss (single phasing) indication
Phase sequence reversal indication
Programmable CT ratio
Calculated neutral current
Auto-ranging for line current and active power display
Measurement Parameters:
True RMS phase and line voltages
True RMS currents
True power factor
Displacement power factor (cos Ф)
Per phase and total power factor
Power line frequency
Bidirectional active power (kW)

Variations

NX301A-240A
NX302A-240A
